SD STRAIGHT DUCT
SD
Mini Split Line set cover of SLIMDUCT SD series.
Architectural Line sets cover: The perfect system SLIMDUCT SD with various fittings will conceal, beautify and protect exposed linesets and is suitable for any split air conditioners.
Good Appearance: Blends in with interior as well as exterior due to stylish compact design.
Assembly: Straight duct cover clips onto top of the base tightly and quickly.
Installation: SLIMDUCT SD can be cut by SLIMDUCT line set cover cutter as well as a hacksaw.
Flame Retardant: SLIMDUCT SD is made from flame retardant materials.
Size: Available in three size, 3", 4". 5-5/8".
Color: Available in five colors: White, Ivory, Brown, Gray, & Black.
Fittings: A full range of various fittings enables to accommodate any complicated configuration. (295 SKUs)
Versatile: For not only HVAC but also plumbing.
Lifetime Protector: SLIMDUCT SD line set cover is constructed from a special high grade PVC for superior UV and weather resistance, protecting line sets from the elements, vandalism and pest damage.
Attentive: Some fittings have a pin on back side of cover of them for preventing the cover of straight duct from sliding. When utilizing this pin, insert the pin into half-opened hole after pushing out this hole. When not using this pin, remove it before installing the cover of fittings.
Caution: Dark colors fade in sunlight sooner than light colors.
| Code No. | Item No. | A | B | C | D | E | Pcs/Bundle |
|---|---|---|---|---|---|---|---|
| C 0402 | SD-77 | 3" | 2-1/2" | 2-3/8" | 2-3/8" | 3" | 15 |
| C 0403 | SD-100 | 4" | 2-7/8" | 3-1/2" | 3-1/2" | 4" | 10 |
| C 0404 | SD-140 | 5-5/8" | 3-1/4" | 4-7/8" | 4-7/8" | 5-3/8" | 5 |
